Irrigation Guide

Sprinklers, MP Rotators, and getting more lawn per litre

Every reticulation system is built from a handful of sprinkler types, and picking the right one for each zone is what separates an even, healthy lawn from dry patches and a high water bill. Here's how the common options compare, and why we default to Hunter MP Rotators wherever they're a good fit.

Pop-up Spray Heads

The standard fixed spray nozzle most Perth gardens already have. Pops up, sprays a fan-shaped pattern, retracts when off. Simple and cheap to install, but applies water fast — often faster than sandy soil can absorb it — which wastes water to runoff on slopes, paths and driveways.

Best for: small garden beds & narrow strips

Gear-Driven Rotors

A single rotating stream that slowly sweeps across a large area. Lower application rate than a spray head and better suited to bigger open lawns, but each head only waters one point at a time, so uniformity over smaller or oddly shaped areas can suffer.

Best for: large open lawns & ovals

MP Rotator Nozzles (Hunter Industries)

Multiple rotating streams from a single nozzle that screws straight onto a standard spray body. Combines the low, soil-friendly application rate of a rotor with the flexibility and easy retrofit of a spray head — our default choice for most suburban Perth lawns.

Best for: most standard-size lawns & retrofits

Drip & Micro-Spray

Low-flow tubing or micro-jets that deliver water directly to the root zone of a plant rather than through the air. Minimal evaporation loss, ideal for garden beds and native planting where we're already designing for water efficiency.

Best for: garden beds, natives & screening plants

🔴 Standard Spray Nozzle

  • Applies water at roughly 1.6 in/hr — far faster than most soils, especially Perth's sandy profile, can absorb
  • Higher rate leads to runoff onto paving and driveways, particularly on slopes
  • Fine mist pattern drifts easily in wind, watering paths instead of lawn
  • Fixed range per nozzle size — more nozzle types needed to cover varied zone shapes

🟢 Hunter MP Rotator

  • Multi-stream design applies water at just 0.4 in/hr (0.8 in/hr on the MP800), letting it soak in rather than run off
  • Rated to use around 30% less water than a traditional spray nozzle for the same coverage
  • Heavier droplet streams resist wind drift far better than a fine spray mist
  • One nozzle range covers everything from a 1.5m strip to an 11m radius, simplifying zone design
  • Screws onto existing spray bodies — an easy retrofit without re-trenching the system
~30%
less water used vs standard spray nozzles
0.4"/hr
application rate — matched to what sandy soil can absorb
1.5–11m
single nozzle range, cutting the number of head types on a job

Because MP Rotators run at a lower flow rate, more heads can often share the one valve — meaning fewer valves, less pipe and less wiring on a new install, and a genuinely easy upgrade path on an existing system since the nozzle simply replaces what's already screwed into the spray body. Figures from Hunter Industries product and design documentation.

Situation Typical fit
Small courtyard or verge strip Standard spray head — cheapest option where the area is too small to benefit from an MP Rotator's range
Standard suburban lawn MP Rotator — best balance of water efficiency, even coverage and retrofit cost
Sloped lawn or verge MP Rotator — slow application rate is the single biggest fix for runoff on a slope
Large open lawn or acreage Gear-driven rotors, sized to the zone
Garden beds & native planting Drip or micro-spray, kept separate from turf zones on its own valve

If your system is still running on old spray heads, retrofitting to MP Rotators is often a same-day job with no re-trenching required. Get in touch for an assessment of your existing zones.
